Trailer Tracking
Trailer Tracking & Monitoring
Keep Tabs on All of Your Trailers
The OneView platform offers user-friendly, web-based trailer tracking applications that allow companies to know the location, current temperature, and actual usage of their trailers.
Key Features
Automatic alarms via email or text
GPS trailer tracking
Easy install
Compact and rugged design
Locate your trailer in seconds
Landmarks and geo-fencing
Long-lasting rechargeable battery
Temperature monitoring
Manage usage-based maintenance
Detailed and actionable reporting
Solar tracking (optional)
Benefits
Real-time Visibility
Deliver accurate estimates with location tracking
Increase Trailer Utilization
Identify trailer usage with automated dormancy and utilization reports
Minimize Trailer Loss
Receive a text or email alert if a trailer leaves a pre-defined geographical area, reducing equipment losss
Decrease Maintenance Costs
Schedule usage-based maintenance, extending trailer life and eliminating unnecessary maintenance costs
Prevent Loss of Goods
Receive a text or email alert when the trailer's temperature goes out of an acceptable range
Technical Specifications
Dimensions | 4G LTE CAT M1 |
Dimensions | 5.1 x 3.6 x 1.9 inches |
Weight | 20.45 oz |
Update Frequency | FM Every minute when moving. Every 30 minutes when not moving. Once per week when not connected to power.
MM Hourly when moving or connected/disconnected from power. Once per week when not connected to power. |
Battery | 5.2 Ah Lithium-ion Internal Battery Life: 4-5 Months @ 1 ping/week |
Electrical Specifications | Operating Voltage: 12/24 VDC Power Consumption: Active Mode: 400mA @ 12V Sleep Mode: 15mA @ 12V Deep Sleep Mode: 60mA @ 12V |
Temperature | -22 to 140° Fahrenheit |
IP Rating | IP66 |
Add-Ons | Temperature Monitoring |
Monitor | Location Connection Status Connected Hours Mileage Speed (FM option only) Temperature Monitoring (add-on) |
